Hager VML955RK 10 Way 5+5 100A Sw 2*100A 30mA RCCB Type A Round KO
Hager 5 + 5 Dual 100A RCD Split Load Metal Clad Consumer Unit with Round Knockouts
- 5 + 5 way split load consumer unit
- Supplied with 2 x 100A 30mA Type A RCDs and 1 x 100A DP isolator
- Selection of round knockouts
- Design 10 consumer units come with top, bottom, rear knockouts and a meter tail cable entry plate
- Comes with a full complement of earth and neutral terminals along with marking labels, busbar and instructions
- Design 10 board has ample cable space available even when RCBOs are fitted. The top mounted terminal rail makes the wiring of the neutral and earth connections neat and simple
- Conforms to BS EN 61439-3 Including Annex ZB
- Board Configuration 5 + 5
- Cable Entry Selection of Round Knockouts
- Colour White
- Current Rating 100A
- Dimensions (H)246 mm x (W)370 mm x (D)100 mm
- Door Type Top Hinged
- Guarantee 1 Years
- Incoming Device 100A Isolator
- Incoming Terminal Capacity 50 mm²
- Knockouts Round
- Material Steel
- Mounting Surface
- Number of Modules 16
- Number of Outgoing Ways 10
- Product Range Design 10
- Rcd Rating 100A
- Rcd Type A
- Standards BS EN 61439-3
- Surge Protection Fitted No
- Surge Protection Ready No
- Tripping Sensitivity 30mA
- Voltage Rating 230V
- Weight 4.7kg
